Mondraker Neat R Light - E-Mountain Bike
Mondraker Neat R Light - E-Mountain Bike
Mondraker Neat R Light - E-Mountain Bike
media.alt
media.alt
media.alt

Description

TRAIL-READY GEOMETRY

Designed for stability on steep descents and agility through technical terrain, the Forward Geometry optimizes handling and comfort. Whether navigating rocky climbs or tight turns, the geometry adapts perfectly to the trail.

SMOOTH & EFFICIENT POWER

Experience the power of the TQ HPR-50 motor, perfect for climbing and conquering trails. The 360Wh integrated, removable battery ensures extended range, supporting long rides without compromising performance.

LIGHTWEIGHT CARBON PERFORMANCE

The full carbon frame offers a lightweight, durable, and stiff design, providing exceptional performance for aggressive riders seeking both speed and control.

PREMIUM SUSPENSION & CONTROL

Fox 36 fork (160mm travel) and Float X rear shock (185x55mm) deliver premium suspension, SRAM G2 R brakes ensure stopping power, and Mavic E-CrossRide wheels with Maxxis Minion tires provide grip and durability for tough trails.

RELIABLE BRAKING

SRAM G2 R brakes with 4-piston calipers, 200mm rotors, and tool-free reach adjust for reliable stopping power and control.

ADVANCED DRIVETRAIN

SRAM GX Eagle 12-speed drivetrain with X-Sync 2 Eagle 34T ring ensures smooth shifting and reliable power transfer.

FOX SUSPENSION

Fox 36 fork (160mm) and Float X shock (185x55mm) provide superior suspension for control and handling on tough terrain.

RUGGED WHEELSET

Mavic E-CrossRide 29-inch rims with Maxxis Minion DHF/DHR II tires offer superior grip, durability, and traction on tough trails.

FULL CARBON FRAME

Stealth Air full carbon frame offers lightweight durability, optimal power transfer, and responsiveness for aggressive riding.

Components

FRAMESET
FRAME
Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal & removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, integrated dropout speed sensor, exclusive plastic motor covers
HEADSET
Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
SUSPENSION
FORK
Fox 36 29 Float GRIP EVOL Performance, 160mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
SHOCK
Fox Float X Performance EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings, Medium compression, medium rebound, air volume spacer 0.4 shock setting
DRIVETRAIN
REAR DERAILLEUR
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
SHIFTER
Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
CRANK
E.13 E*Spec Plus, S size: 165mm M size: 165mm L size: 170mm XL size: 170mm
CHAINRING
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
CASSETTE
Sram PG-1230, 11-50T, 12s
CHAIN
Sram NX Eagle, 12s, Powerlock
E SYSTEM
BATTERY
TQ HPR-50 360Wh integrated and removable. Optional external battery: TQ 160Wh
COMPUTER
TQ HPR display V01
MOTOR
TQ HPR-50 Motor, Mid-drive, 50 Nm torque, 250W continuous power, 1.85 kg, compact, ultra-quiet, high efficiency, and natural ride feel
DISPLAY
TQ HPR display V01
BRAKES
FRONT BRAKE
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
REAR BRAKE
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
ROTOR
Front: 200mm Centerline Rotor (Sram G2 R). Rear: 200mm Centerline Rotor (Sram G2 R)
WHEELS
FRONT HUB
Mavic, Boost 15x110mm, IS 6 bolts
REAR HUB
Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
RIM
Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
TYRE
Front: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead. Rear: Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
MAX TYRE SIZE
29x2.5 (Front) 29x2.4 (Rear)
CONTACT POINTS
SADDLE
Fizik Terra Aidon Slim X5
SEATPOST
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm
HANDLEBAR
Onoff Krypton 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
GRIPS
Onoff Desert, 1lock-on, 135mm
STEM
Onoff Krypton FG 30mm, CNC, 31.8mm barbore
WEIGHT
BIKE WEIGHT
41.7 lbs

Geometry

Frame Size S
(5'5"–5'9")		 M
(5'9"–6'1")		 L
(6'1"–6'5")		 XL
(6'5"+)
A Seat Tube Length 14.96" 16.54" 17.72" 19.29"
B Top Tube Length 23.43" 24.21" 25.20" 25.98"
C Bottom Bracket Drop -0.98" -0.98" -0.98" -0.98"
D Bottom Bracket Height 13.70" 13.70" 13.70" 13.70"
E Chainstay Length 17.72" 17.72" 17.72" 17.72"
F Seat Tube Angle 72.6° 72.6° 72.6° 72.6°
G Effective Seat Tube Angle 76.5° 76.5° 76.5° 76.5°
H Head Tube Angle 64.5° 64.5° 64.5° 64.5°
I Fork Offset 1.73" 1.73" 1.73" 1.73"
J Wheelbase 48.62" 49.41" 50.20" 50.98"
K Head Tube Length 4.33" 4.33" 5.12" 5.51"
L Reach 17.72" 18.50" 19.49" 20.28"
M Stack 24.65" 24.65" 25.28" 25.59"
Customer Reviews
5.0 Based on 1 Reviews
5 ★
100%
1
4 ★
0%
0
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Customer Photos
Mondraker Neat R Light - E-Mountain Bike - Customer Photo From Kevin Masticolai
