Description

CROSS-COUNTRY ADVENTURES

So, you're new to mountain biking and want a high-value bike with progressive modern geometry perfect for local XC trails, racing or multi-day adventures? The Xtrada is your ticket to ride with a capable and lightweight aluminium frame that will take you anywhere you want to go.

VALUE MEETS PERFORMANCE

Tackle any climb with the Xtrada 7's wide-range Shimano Deore 1x12 drivetrain, providing smooth and precise shifting across a 10-51T cassette. The Shimano MT200 hydraulic disc brakes offer reliable stopping power while the 120mm of air-sprung suspension gives you the confidence to push your limits on the descents.

A TRUSTED BRAND

Polygon is a factory-direct brand with over 30 years of experience crafting high-performance bikes at competitive prices. Vertically integrated manufacturing ensures quality and cost savings. Their mountain bikes have been tested on the world stage at events like Redbull Rampage and the World Cup circuit, boasting a 5-year frame warranty for peace of mind.

MODERN DESIGN

Light, durable, and hydroformed, the 6061 aluminium frame features a threaded bottom bracket, internal cable routing, and boost rear axle spacing.

AIR SPRUNG

The Xtrada comes equipped with a 120mm air spring and thru-axle forks – RST Aerial-15 in 27.5” & Suntour XCR32 in 29”. Both of which offer a controlled and smooth ride.

SHIMANO DEORE 1X12 DRIVETRAIN

The Shimano Deore 1X12 drivetrain is paired with an 11-51T cassette, giving you a +500% gear ratio to get up and down the mountain with ease.

Components

FRAMESET
FRAME
ALX XC Sport 6061 Aluminum Frame, Smooth Welding Technology, Internal Cable Routing, Tapered Headtube, 73mm Threaded Bottom Bracket, Boost Rear Thru-Axle 12x148mm
SUSPENSION
FORK
Suntour XCR32, 120mm, Air Spring, Tapered Steerer, 15mm Thru-Axle
DRIVETRAIN
REAR DERAILLEUR
Shimano Deore RD-M6120, Shadow+, Direct Mount, 12-Speed
SHIFTER
Shimano Deore SL-M6100, 12-Speed
CRANK
Shimano Deore FC-M510
CHAINRING
32T
CASSETTE
Sunrace CSMZ-800, 11-51T, 12-Speed
CHAIN
KMC X-12 12-Speed
BRAKES
FRONT BRAKE
Shimano BL-M201 Hydraulic Disc, 160mm Rotor
REAR BRAKE
Shimano BL-M201 Hydraulic Disc, 160mm Rotor
WHEELS
REAR HUB
Novatec D462SB-SL, 12x148mm 32h, Center Lock
RIM
Entity XL2 Disc, Alloy Rims, 30mm Internal Width, Tubeless Tape Installed
TYRE
WTB Trail Boss Comp, 2.25"
CONTACT POINTS
HANDLEBAR
Entity Expert
SADDLE
Entity Void
SEATPOST
Entity Expert, Zero Offset, 27.2x350mm
STEM
Entity Expert, 31.8mm Clamp
WEIGHT
BIKE WEIGHT
30lbs (Size L)

Geometry

  S M M L XL
Wheel Size 27.5" 27.5" 29" 29" 29"
Rider Height 5'2" – 5'6" 5'6" – 5'10" 5'6" – 5'10" 5'10" – 6'1"  6'1" – 6'5"
(A) Stack 593 599 629 633 637
(B) Reach 410 430 430 450 470
(C) Head Tube Angle 67° 67° 67° 67° 67°
(D) Head Tube Length 95 100 95 100 105
(E) Seat Tube Angle 75° 75° 75° 75° 75°
Seat Tube Angle Effective 75° 75° 75° 75° 75°
(F) Seat Tube Length 385 425 425 460 500
(G) Top Tube Effective 569 590 598 619 640
(H) Bottom Bracket Height 310 310 309 309 309
(I) Bottom Bracket Offset 45 45 65 65 65
(J) Chainstay 425 425 435 435 435
(K) Wheel Base 1106 1128 1147 1169 1191
(L) Standover Height 663 697 693 715 751
Fork Travel 120 120 120 120 120
Handlebar Width 760 760 760 760 760
Stem Length 40 40 40 40 40
Crank Length 170 170 170 175 175

* All lengths in mm

Assembly

Your bike needs minor assembly before riding; use the tools and videos included.

As a guide, it'll take 10-40min depending on whether you're an experienced bike assembler or have little to no mechanical experience.

Side Note: Your cables will stretch during the initial bed-in period and must be adjusted by an experienced mechanic around 150km of riding.

Step 1

Unboxing Your 2024 Polygon Xtrada 7 1x12

Step 2

Bike Fit Setup

Step 3

Tyre Pressure Setup

Step 4

https://cdn.shopify.com/videos/c/o/v/62652704734f4732a541f4edd69a0193.mp4
